Description
FEATURES:
- High Grade Ferrite Magnet
- 25mm Copper Voice Coil
- Kapton Coil Former
- Heavy Gauge Steel Basket
- Reinforced Paper Cone
- Custom Cloth Surround
SPECIFICATIONS:
| Nominal Impedance | 8 Ohms |
| RMS Watts | 60 W |
| Peak Power | 240 W |
| Usable Frequency Range | 448Hz -7KHz |
| Sensitivity | 97 dB |
| Mechanical Q (Qms) | 7.1 |
| Electromagnetic Q (Qes) | 10.7 |
| Total Q (Qts) | 4.2 |
| Compliance Equivalent Volume (Vas) | 0.322 liters |
| Mechanical Compliance of Suspension (Cms) | 4.7 uM/N |
| BL Product (BL) | 7.1 TM |
| Surface Area of Cone (Sd) | 0.013 Sqm |
| Mounting Holes Diameter | 218 x 152 |
| Mounting Depth | 3.43″, 87mm |
| Shipping Weight | 3.92 Lbs, 1.78 Kgs |
| Basket Materials | Stamped Steel |
| Cone Composition | Paper Cone |
| Cone Edge | Composition Dust Cap |
| Dust Cap Composition | Paper Dustcap |
