Description
The Quantum QEA500.4, QEA800.4, QEA800.2 are equipped with a built in variable crossover network allowing you to select the crossover function and frequency for each the front channels or rear channels of the amplifier independently.
- Class A/B Circuitry
- 2 Ohm Load Stereo Capability
- Audiophile Grade Components
- Variable Low/ High Pass Crossover
- High Efficiency Mosfet Design
- QSINK Heat Management System
PHYSICAL STRUCTURE
| Length (A) | 11.73″ / (296mm) |
| Width (B) | 9.54″ / (242.35mm) |
| Height (C) | 1.96″ / (50mm) |
| GENERAL SPECIFICATIONS | |
|---|---|
| Rated Power @ 14.4 Volts | |
| Dynamic Power Handling | 4 X 160 Watts @ 4Ω Stereo |
| Dynamic Power Handling | 4 X 320 Watts @ 2Ω Stereo |
| Dynamic Power Handling | 2 x 640 Watts @ 4Ω Bridged |
| PARAMETERS | |
|---|---|
| Signal to Noise ratio: | >90dB |
| Ch 1-2 High Pass Crossover: | 20Hz – 250Hz |
| Ch 3-4 High Pass Crossover: | 20Hz – 250Hz |
| Ch 3-4 Low Pass Crossover: | 50Hz – 250Hz |
| X-Over Slope: | 12 dB |
| THD at Rated Power: | <0.5% |
| Input Sensitivity: | 285mV-6V |
| Bass Boost @ 45Hz: | 0-12dB |
4 CHANNEL AMPLIFIER SPEAKER CONNECTION
(DIAGRAM 1)
4 CHANNEL AMPLIFIER SPEAKER CONNECTION
(DIAGRAM 2)
REMOTE CONNECTION
