DB Drive 4 CHANNEL AMPLIFIER- WDX300.4 G2
DB Drive 4 CHANNEL AMPLIFIER- WDX300.4 G2 - Image 2
DB Drive 4 CHANNEL AMPLIFIER- WDX300.4 G2 - Image 3
DB Drive 4 CHANNEL AMPLIFIER- WDX300.4 G2 - Image 4

DB Drive 4 CHANNEL AMPLIFIER- WDX300.4 G2

Winning Bid: $75.00

Up for auction is a 4 channel amplifier by DB Drive. If your looking for a good amp for your mid’s and hi’s, then this is the amp for you!! As Always, $1 no reserve!! Good Luck and Happy Bidding!!

Item condition: New

Category: Tags: , , , , , , , , ,

Description

The DB Drive WDX amplifiers includes built-in variable crossovers. The WDX300.4G2, WDX400.4G2 and WDX800.4G2 also offers independent 12dB per octave High Pass and Low Pass X-Over Network. For added low frequency performance the amplifiers are equipped with a selectable6dB-12dB bass boost @ 45Hz

  • 2Ω Stereo Capability
  • Blue LED POWER-ON Indicator
  • Variable Low Level RCA Input
  • Variable 12DB Per Octave Low-Pass X-Over
  • Direct- Connect Connection Terminals
  • Buffered Pre-amp input
  • Selectable 6dB-12dB Boost @ 45Hz
  • DRIVESINK Heat Management System
  • Unregulated DB-DC PWM Power Supply
  • Speaker Short Circuit Protection

PHYSICAL STRUCTURE

Length (A) 8.66″ / (220mm)
Width (B) 7.08″ / (180mm)
Height (C) 2.25″ / (57.15mm)



GENERAL SPECIFICATIONS
Rated Power @ 14.4 Volts
Dynamic Power Handling 4 x 60 Watts @ 4Ω
2 x 180 Watts @ 4Ω Bridged4 x 120 Watts @ 2Ω
PARAMETERS
Frequency Response 10Hz ~ 250Hz
S/N Ratio < 105 dB
Independent Selectable X-Over F/R HPF / LPF /LP-BP
Variable High Pass Filter 50Hz ~ 5KHz
Variable Low Pass Filter 50Hz ~ 500Hz
Damping Factor 200m<

Additional information

Weight 7 lbs
Dimensions 15 × 9 × 5 in
