Description
- ATC – Audiophile Grade Tiffany RCA Connectors
- ACT – Adaptive Crossover Technology
- High efficiency Class D Technology
- Direct Connect Speaker Terminals
- 4 Gauge Power Wire Inputs
- APC – Audio Protection Circuit
- SESI – Signal Evaluation Status Indicator
- Bass Remote with status indicator
- CHM – Collective Heat Management
- DRIVE-LINK- for easy multi-linking of two like amplifiers
PHYSICAL STRUCTURE
| Length (A) | 7.08 in (180mm) |
| Width (B) | 9.13 in (232mm) |
| Height (C) | 2.53 in (64.5mm) |
| GENERAL SPECIFICATIONS | |
|---|---|
| Rated Power @ 14.4 Volts | |
| 1 x 1250 Watts @ 1Ω | |
| 1 x 625 Watts @ 2Ω | |
| 1 x 300 Watts @ 4Ω |
| SPECIFICATIONS | |
|---|---|
| Working Voltage | 9-16 Volts |
| Frequency Response | 15Hz – 270Hz |
| Signal to Noise Ratio | <98dB |
| Damping Factor | 230dB< |
| Low Level Input | 6V – 0.2V |
| Subsonic Filter | 10Hz – 50Hz |
| Bass Boost | 0-dB – 12dB |
| Low Pass Filter Variable | 35Hz – 250Hz |
| Minimum Working Impedance | 1 Ohm |
SIGNAL CONNECTION
DIAGRAM:
SPEAKER CONNECTION DIAGRAM 1:
SPEAKER CONNECTION DIAGRAM 2:
