Description
Features
- 2.5″ High Temperature Voice coil
- 4 Ohm DVC
- Magnet Size = 100 oz
- Reinforced Paper cone
- Double stitched foam surround
- Dual poly-cotton dampeners
- Stamped Cast basket
- Rubber gasket trim ring
- Large Gauge compression terminals
- Protective magnet cover
Specifications
| Nominal Power: 500 Watts |
| Dynamic Power: 1000 Watts |
| Resonant Frequency (fs): 36.392 Hz |
| DC Resistance (Re): 1.9Ā x 2Ā ā¦ |
| Mechanical Q (Qms): 2.192 |
| Electromagnetic Q (Qes): 0.432 |
| Total Q (Qts): 0.361 |
| Compliance Equivalent Volume (Vas): 19.199m |
| Mechanical Compliance of Suspension (Cms): 102.579u |
| BL Product (BL): 9.681 N/A |
| Diaphragm Mass inc. Airload (Mms): 186.453 gr |
| Sound Pressure Level (SPL): 85.2dB |
| X-MAX: 14mm |
| Box Specs |
| Sealed Box: 0.8 cu ft (22.65 L) |
| Vented Box: 1.39 cu ft. (39.36 L) |
| Vent Area: 12.57 sq in. (81.57 cm2) |
| Vent Length: 13in (33.02cm) |
| Box Tuning: 40 Hz |
Description
Unleash the full potential of your audio system with the DB Drive WDX10G0.2 subwoofer. Designed with precision and crafted for excellence, this 10-inch powerhouse boasts a high-temperature voice coil and a reinforced paper cone for superior sound quality. Its double-stitched foam surround and dual poly-cotton dampeners ensure durability and resilience, while the stamped cast steel vented basket and rubber gasket trim ring offer robust construction. With a 1000-watt max power and 500-watt nominal power, this subwoofer delivers an explosive audio experience. The large gauge compression terminals and protective magnet cover add the finishing touches to this incredible piece of audio technology. Whether you’re a casual listener or an audiophile, the WDX10G0.2 promises to elevate your sound journey to extraordinary heights.
Product ManualĀ
Product Manual PDF
