Description
Features
- Class D Technology
- Direct Connect Speaker Terminals
- Large Gauge Power Wire Inputs
- PWM Mosfet Regulated Power Supply
- APC – Audio Protection Circuit
- SESI – Signal Evaluation Status indicator
- CHM – Collective Heat Management
- 1Ω Capability
- Remote Bass Control Included
Specifications
| Rated Power: 1 x 1250 Watts @ 1Ω |
| Rated Power: 1 x 625 Watts @ 2Ω |
| Rated Power: 1 x 300 Watts @ 4Ω |
| Crossover Slope: @ 24dB |
| Low Pass Filter: 40Hz – 250Hz |
| Subsonic Filter: 10 – 50 Hz |
| Bass Boost @ 45Hz : 0-12dB |
| Input Sensitivity: .425Mv – 8.5V |
| Signal to Noise Ratio :>110dB |
| DIMENSIONS: |
| L – 9.24″/ 234.6 mm |
| W – 5.51″/ 140 mm |
| H – 1.97″/ 50 mm |
