Description
- Class A/B Circuitry
- 2 Ohm Load Stereo Capability
- Low level RCA inputs
- Selectable HP/LP *2 Channel / Selectable HP/LP/BP *4 Channel
- High Efficiency Mosfet Design
- Heat Management System
- Bridgeable outputs @4Ohm load
PHYSICAL STRUCTURE
| Length (A) | 6.9″ / (175mm) |
| Width (B) | 6″ / (153mm) |
| Height (C) | 2″ / (55mm) |
| GENERAL SPECIFICATIONS | |
|---|---|
| Rated Power @ 14.4 Volts | |
| Dynamic Power Handling | 2 x 150 Watts @ 4Ω |
| Dynamic Power Handling | 2 x 375 Watts @ 2Ω |
| Bridged | 1 x 750 Watts @ 4Ω |
| SPECIFICATIONS | |
|---|---|
| THD at Rated Power | 0.5% |
| Bandwidth | (-3 dB) -18Hz- 22Hz |
| Damping Factor | (1k Hz @4Ohm) – 100 |
| Signal to noise ratio | >90dB |
| Input Sensitivity | 285Mv- 6V |
| Minimum Load Impedance | 2 Ohm Stereo |
| Input | Pre in RCA |
| Crossover Filter Slope In Stereo | 12dB |
| Channel 1-2 HP Filter Range | 20Hz-5KHz |
| Channel 3-4 LP/BP Filter Range | 50Hz-500Hz |
| Selectable Bass Boost (@45 Hz) | 0-12 dB |
