Description
DS18 PRO-DR1.35
1” Twist On Throat Compression Driver with 1.35” Titanium VC 400W 8 Ohm
DS18’s PRO-DR1.35 is a must have in any audio system – this game changing 1” Twist On Throat Compression Driver is designed to bring soaring highs to any vehicle’s sound system.
Your system reaches new heights with the PRO-DR1.35’s impressive power handling capabilities. The PRO-DR1.35 effortlessly manages an astounding 200W RMS power and an awe-inspiring 400W MAX power. Its raw strength envelops your ears in a cascade of unfiltered, unparalleled sound.
Give in to the charm of the PRO-DR1.35’s impressive high sensitivity, clocking in at a remarkable 103 dB. This translates to mesmerizing audio clarity that lets you soak in the vibes without using your systems full power limitations. Ranging from 500Hz to 20KHz, these drivers will indulge your senses with exhilarating highs, infusing every note with electrifying energy.
Think of the titanium diaphragm as the heartbeat of the PRO-DR1.35 – the very soul of the driver, ensuring every beat, every note is as vivid and timeless as your favorite melodies.
The PRO-DR1.35 steps up as a high-powered DS18 high-frequency driver, embracing the essence of innovation to create sound projection like no other. Its friendly compatibility with all DS18 screw-on throats let you dial in a look that’s as unique as your groove.
Built with an unshakable commitment to top-notch quality, the PRO-DR1.35 comes with high-grade terminals that lock in your connections, making sure they smoothly blend into your audio setup. And the cherry on top? Swapping out voice coils is a breeze, a clear nod to our promise of making your passion towards audio easier.
TECHNICAL DATA
SPECS
SKU- PRO-DR1.35
Nominal Impedance- 8 ohms
Throat Diameter- 1″
RMS Power Handling- 200W
MAX Power Handling- 400W
Sensitivity (1w/1m)- 103dB
Frequency Response- 500Hz-20KHz
Recommended Hi Pass Crossover- 800 Hz
Voice Coil Diameter- 1.35″
Diaphragm Material- Titanium
Magnet Material- Ferrite
Magnet Weight- 16 oz.
Bolt Type- Screw Down
MEASUREMENTS
Overall Diameter- 3.54″ / (90mm)
Overall Depth- 2.51″ / (64mm)
Product Weight- 2.5 lbs
Product Dimensions- 5 x 5 x 3.5
PRO-H44BLK
TECHNICAL DATA
SPECS
SKU- PRO-H44
Material- PC/ABS
Profile- Circular
Coverage- 45° x 45°
Throat Diameter- 1″
Depth- 2.71″
Installation Method- Twist
MEASUREMENTS
Overall Diameter- 4.52″ / 115mm
Mounting Depth- 2.71″ / 69mm
Overall Depth- 3″ / 76.5mm
Product Weight- 0.33 lbs
Product Dimensions- 4.75 x4.75 x 3.25
