Description
Features
| Class D Mono Block Amplifier |
| 1 Ohm Stable Capability |
| PWM Mosfet power supply |
| RCA line level Stereo inputs |
| 4 Layer PCB |
| Variable 12dB Low Pass Crossover |
| Variable 12dB Subsonic Filter |
| Variable Bass Boost @ 45 Hz |
| Heat management system |
| Selectable input gain range |
| Remote Bass Control Included |
Specifications
| 1 x 1800 Watts @ 1Ω |
| 1 x 900 Watts @ 2Ω |
| Low Pass Filter: 40Hz – 300Hz |
| Subsonic Filter: 0 – 25 Hz |
| Bass Boost @ 45Hz : 0-12dB |
| Input Sensitivity: 250Mv – 6V |
| Signal to Noise Ratio : >90dB |
| Frequency Response:10Hz-250Hz |
| DIMENSIONS: |
| L: 10.20″ / 260mm |
| W: 5.50″ / 140mm |
| H: 2″ / 51mm |
Description
Product Manual
