Description
FEATURES:
| 2 Channel Digital Bass Restoration W/ Full Range Pass Through |
| Variable Center Frequency Control |
| Selectable Output Gain Limiter |
| Dash Mount Remote Control |
SPECIFICATIONS:
| Operating Voltage: 9-16V DC |
| Maximum Input Level: 10 Vrms |
| Maximum Output Level: 10 Vrms |
| Frequency Response: 10 Hz – 600KHz; +/- 3dB |
| Total Harmonic Distribution: 0.01% |
| Signal To Noise Ratio: -95dB |
| Balanced Input Noise Rejection: >60 dB |
| Channel Separation @ 1KHz: > 80dB |
| Input Impedance: 20 K Ohms |
| Output Impedance: <50 Ohms |
| Power Supply: High Headroom PWM |
| Power Draw: 150mA |
| Recommended Fuse Rating: 1 Amp |
