Description
Amplifier Module Taramps HD 15000 15000w rms 1 ChannelThe HD line is a line of high-power amplifiers that allows you to reproduce sub, bass and mid-high-pitches in high definition.
The Taramps HD 15000 Amplifier Module is the brand’s newest release and has red accents on its housing, giving it a unique design in the HD line! The Class D Power is mounted with SMD technology, guaranteeing the high effectiveness in battery consumption, in addition to its size and reduced weight.
It has 1 channel of 15000 RMS, initially available in 1 OHM and frequency response from 10Hz to 10kHz with low harmonic distortion. To have full use of the loudspeakers in your automotive sound system, it has a built-in variable crossover (H.P.F – L.P.F) with 12dB / 8a power and can be used with high performance Subwoofers, Woofers and Mid Bass.
The Taramps HD15000 for added convenience and safety in its use, has a built-in digital voltmeter that shows the real-time voltage of the batteries, in addition to having a traditional taramps LED monitor, allowing the user to monitor the indicator function indicators, clip and amplifier protection, from elsewhere in your car, helping to avoid burning the speakers.
The new amplifier module is perfect for anyone who uses a high-power automotive sound system in Brazil, wants excellent sound definition and more practicality in use, and is also the most winning brand in the national automotive sound championships in recent years!
Technical specifications of the Taramps HD 15000 module:
Model 2 ohms
Maximum Power @ 13.8VDC – 2 OHMS: 18,000W RMS
Maximum Power @ 13.8VDC – 4 OHMS: 13.104W RMS
Maximum Power @ 12.6VDC – 2 OHMS: 15,000W RMS
Maximum Power @ 12.6VDC – 4 OHMS: 10.920W RMS
Input Sensitivity: 220mV @ -13.15dBm
Signal to Noise Ratio: ˃95dB
Damping Factor: ˃500
Frequency Response Full Range: -3dB @ 10Hz @ 10KHz
Crossover High Pass (HPF): 10Hz to 80Hz (-12dB / 8 ͣ) Variable
Crossover Low Pass (LPF): 80Hz to 10KHz (-12dB / 8 ͣ) Variable
18K OHMS Input Impedance
Short Output Protection System and Low Output Impedance, Low Voltage, High Voltage and Thermal Protection
Minimum Power Supply Voltage: 9 VDC
Maximum Power Supply Voltage: 16 VDC
Consumption at rest @ 12.60 VDC: 4.3A
Maximum Musical Consumption @ 12.6 VDC: 791.50A
Maximum Sine Power Consumption @ 12.6 VDC: 1.583.15A
Dimensions (WxHxD) 268.7 x 72 x 519mm
Weight: 8Kg
Taramps HD 15000 Amplifier Module Comes with:
– Bumper Sticker Taramps.
– Manual.
– Allen key.
– Led monitor.
Brand Name: Taramps.
