Description
FEATURES:
- 4 Channel Class A/B Amplifier
- 2Ω Stereo Load Capability
- Selectable Crossover: HPF/LPF/BP
- Bridgeable Outputs @ 4Ω Load
- 4 Gauge Power Cable Input Connectors
- Double Sided PCB
- Compatible with any 4/2Ω Loudspeaker
| SPECIFICATIONS: | |
|---|---|
| Rated @14 Volts |
|
| THD (1kHz @ 4Ω) | 0.04% |
| Bandwidth (-3 dB) | 18Hz- 22KHz |
| Input Sensitivity | .20MV – 5.0V RMS |
| Signal to Noise Ratio | 99dB |
| Damping Factor (1k Hz @ 4Ω) | 100 |
| DIMENSIONS | |
|---|---|
| Length | 11.61″ / 295 mm |
| Width | 6.98″ / 177.4 mm |
| Height | 1.93″ / 49 mm |
