Description
Features
| Class D Mono Block Amplifier |
| 1 Ohm Stable Capability |
| PWM Mosfet power supply |
| RCA line level Stereo inputs |
| Double Sided PCB |
| 12dB / Variable Low Pass Crossover |
| Variable Subsonic Filter |
| Selectable Bass Boost @ 45 Hz |
| Thermal Protection Circuitry |
| Wired Remote Bass Control Included |
Specifications
| Power @ 1 Ohm mono | 2200 watts |
| Power @ 2 Ohm mono | 1100 watts |
| Signal to Noise Ratio | >90dB |
| Low Pass Crossover | 50Hz-220Hz |
| Subsonic Filter | 0 – 50Hz |
| Bass Boost @ 45 Hz | 0-6dB-12db |
| Frequency Response | 10Hz-250Hz |
| THD @ 1 % | <0.1% |
| Input Sensitivity | 200mV-6V |
| Length: 10.82″ | |
| Width: 6.10″ | |
| Height: 2.20″ |
