Description
FEATURES:
- 4 Channel Full Range Class D Circuitry
- 1 Ω Stereo load Capability
- Low Level RCA inputs
- Selectable Crossover: HPF/LPF/Full
- Bridgeable outputs @ 2Ω load
- Compatible with any 4/1Ω Loudspeaker
- High Efficiency Mosfet Design
- Heat Management System
| Length (A) | 8.97″ / (228mm) |
| Width (B) | 6.29″ / (160mm) |
| Height (C) | 2.61″ / (66.29mm) |
| GENERAL SPECIFICATIONS | |
|---|---|
| Rated Power @ 14.4 Volts | |
| 4 x 500 Watts @ 4Ω | |
| 4 x 1000 Watts @ 2Ω | |
| 2 x 2000 Watts @ 2Ω Bridged |
| PARAMETERS | |
|---|---|
| Bandwidth(-3dB) | 18Hz – 22KHz |
| S/N Ratio | < 90 dB |
| Input Sensitivity | 285Mv – 6V |
| Minimum Load Impedance | 1Ohm Stereo |
| Input | Pre in RCA |
| Crossover Fire Slope in Stereo | 12dB |
| Channel 1-2 HPF range | 15Hz-6KHz |
| Channel 1-2 LPF range | 50Hz-6KHz |
| Channel 3-4 HPF range | 15Hz-6KHz |
| Channel 3-4 LPF range | 50Hz-6KHz |
