Description
Features
| 4 Channel Full Range Class D Circuitry |
| 1 Ω Stereo load Capability |
| Low level RCA inputs |
| Selectable Crossover: HPF/LPF/Full |
| Bridgeable outputs @ 2Ω load |
| Compatible with any 4/1Ω Loudspeaker |
| High Efficiency Mosfet Design |
| Heat Management System |
Specifications
| 4×500 Watts @ 4 Ω Stereo |
| 4 x 1000 Watts @ 1Ω Stereo |
| 2 x 2000 Watts @ 2Ω Bridged |
| THD at Rated Power <0.5% |
| Bandwidth (-3 dB) – 18Hz- 22KHz |
| Damping Factor (1k Hz @ 4Ω) – 100 |
| Signal to Noise Ratio >90dB |
| Input Sensitivity: 285Mv – 6V |
| Minimum Load Impedance – 1Ω Stereo |
| Input : Pre in RCA |
| Crossover filter slope in stereo – 12dB |
| Channel 1-2 HPF range – 15Hz -6KHz |
| Channel 1-2 LPF range – 50Hz – 6KHz |
| Channel 3-4 HPF range – 15Hz -6KHz |
| Channel 3-4 LPF range – 50Hz – 6KHz |
| Selectable Bass Boost @45Hz – 0-12dB |
| Dimension |
| L=8.97″ |
| W=6.29″ |
| H= 2.61″ |
