Description
The Quantum: QPX2000.1M, QPX2500.1D, QPX3000.1D, QPX4000.1D and QPX5000.1D are equipped with a built in variable low pass crossover network allowing you to select the crossover function and frequency for each the front channels or rear channels of the amplifier independently.
- Class D Monoblock Amplifier
- 1 Ohm Stable Capability
- Amber-Glow Logo Badge
- Audiophile Grade Components
- Speaker Short Circuit Protection
- High Efficiency Mosfet Design
- 12 dB Variable Low Pass X-over
- 12 dB Variable Bass Boost
- 12 dB Variable Subsonic Filter 15Hz~ 55Hz
- Double Sided PCB
- Bass Remote Included
| Length (A) | 11″ / (280mm) |
| Width (B) | 8.6″ / (220mm) |
| Height | 1.96″ / (50mm) |
| GENERAL SPECIFICATIONS | |
|---|---|
| Rated Power @ 14.4 Volts | |
| Dynamic Power Handling | 1 X 2500 Watts @ 1Ω Mono |
| Dynamic Power Handling | 1 x 1250 Watts @ 2Ω Mono |
| PARAMETERS | |
|---|---|
| Signal to Noise ratio: | >90dB |
| Variable Subsonic Filter: | 15Hz – 55Hz |
| Low Pass Crossover: | 50Hz-220Hz |
| Bass Boost @ 45Hz: | 0-12db |
| Phase Shift Control: | 0-180 degree |
| THD at Rated Power: | 1 % <0.1% |
| Input Sensitivity: | 200mV-6V |
| Frequency Response | 10Hz – 220Hz |
