Description
Features
- 2″ High Temperature 4 Layer Voice coil
- Compressed Paper cone
- Double Stitched High Excursion Foam Surround
- Stamp-cast basket
- PVC Mounting Gasket
- Large Gauge Spring Terminals
- Protective magnet band
Specifications
| Nominal Impedance : 4+4Ω |
| Speaker Sensitivity : 84dB |
| Nominal Music Power : 350 Watts |
| Maximum Music Power : 1200 Watts |
| Dimensions |
| Overall Diameter: 8.43″/ 214 mm |
| Mounting Depth: 4.55″/ 115.5 mm |
| Cutout Diameter: 7.20″/ 182.97 mm |
| TS PARAMETERS |
| Resonant Frequency (fs): 41.1 Hz |
| D.C. Voice Coil Resistance (Re): 4Ω |
| Mechanical Quality Factor (Qms): 3.8 |
| Electrical Quality Factor (Qes): 0.44 |
| Total Quality Factor (Qts): 0.4 |
| Equivalent Air Volume to Cms (Vas): 7.98 L |
| Cms: 0.154 mm/N |
| Mass of Diaphragm/Coil (Mms): 98 g |
| Force Factor (BL): 9.8 N/A |
| Sound Pressure Level (SPL): 84 dB |
