Description
Features
| Full Range Class D Monoblock circuitry |
| 1Ω Load Mono Capability |
| Low level RCA inputs |
| High Level Inputs |
| Variable HP/LP Crossover |
| High Efficiency Mosfet Design |
| Heat Management System |
| Remote Dash Bass Control |
Specifications
| 1 x 2500 Watts @ 1Ω Mono |
| 1 x 1500 Watts @ 2Ω Mono |
| 1 x 750 Watts @ 4Ω Mono |
| THD at Rated Power <0.5% |
| Bandwidth (-3 dB) – 18Hz- 20KHz |
| Damping Factor (1k Hz @ 4Ω) – 126 |
| Signal to Noise Ratio >90dB |
| Input Sensitivity: 285Mv – 6V |
| Minimum Load Impedance – 1Ω mono |
| Mono Low Pass Filter Slope – 12dB |
| LPF range – 40Hz-10KHz |
| HPF range – 15Hz-1KHz |
| Variable Bass boost @ 45Hz |
| Dimensions |
| L- 6.05 in (153.7mm) |
| H- 2.33 in (59.2mm) |
| W- 5.53 in (140.5mm) |
