Driven DRW10D4 10″ High Performance 500W RMS Subwoofer(pair) $1 Shipping!!

Current bid: $6.00

Up for auction is a pair of 10″ Sound Quality subwoofers from DB Drive. Don’t have a lot of real estate to work with in your vehicle but need that knock? These are the ones for you!! Bid Now and don’t miss out!! Best of Luck and Happy Bidding!!

Item condition: New

Time left:

Auction ends: June 25, 2026 9:25 PM
Timezone: America/New_York

Estimated Shipping: $ - $
Non-Continental Estimate: $

*Estimated shipping varies based on customer distance from warehouse

Add to watchlist!

Category: Tags: , , , , , ,

Description



Features:

  • Non-Pressed Paper cone
  • Double stitched foam surround
  • Dual poly-cotton dampeners
  • Die-cast aluminum vented basket
  • Rubber gasket trim ring
  • Large Gauge compression terminals
  • Protective magnet cover

Specifications:

Physical Structure

Outside Diameter (A) 10.87″ (276.00mm)
Mounting Depth (B) 6.15″ (156.30mm)
Cutout Diameter (C) 9.32″ (236.71mm)
General Specifications
Structure 10″ (25.4cm) Woofer
Dynamic Power Handling 2000 Watts
Nominal Power Handling 500 Watts
Impedance 3″ BASV High Temperature Voice Coil
Parameters
Resonant Frequency (fs) 41.63Hz
D.C. Voice Coil Resistance (Re) 3.2Ω x 3.2Ω
Mechanical Quality Factor (Qms) 3.156
Electrical Quality Factor (Qes) 0.582
Total Quality Factor (Qts) 0.492
Equivalent Air Volume to Cms (Vas) 9.79 L
Mass of Diaphragm/Coil (Mms) 289.93 g
Force Factor (Bl) 14.437
Sound Pressure Level (SPL) 82.7 dB

Enclosures:

Recommended Enclosures

Woofer Cut-out 9.32″ (236.71mm)
Mounting Depth 6.15″ (156.30mm)
Sealed Box 1 ft2 (28.32L)
Vented Box 1.2 ft2 (33.98L)
• Vent Area 7.7 in2 (45.6 cm2)
• Vent Length 11″ (27.94 mm)
• Tuning 36Hz
Dynamic Power 2000 Watts
Nominal Power 500 Watts
