Description
Overview
Own the moment on the water with A Higher Standard of Sound.
Compact yet capable, the EMA-600.4 energizes your system with smooth, consistent power that keeps your music alive on every journey.
Features
-
High Efficiency Class D Technology – Delivers powerful sound while using energy efficiently, helping your system run cooler and reducing strain on your boat or vehicle’s electrical system.
-
IPX7 Rated Design with Water-Resistant Integrated Wiring Harness – Built to handle wet environments. The amplifier is sealed to resist water exposure, and the included wiring harness is designed to help keep connections protected from moisture.
-
Bottom-mounted control panel with hydro-sealed cover – All tuning controls are located on the bottom of the amplifier and protected by a sealed cover to help prevent water and dirt from getting inside.
-
ACT – Adaptive Crossover Technology – Automatically directs the right sound frequencies to the right speakers, helping your system produce clearer, more balanced audio.
-
APC – Audio Circuit Protection – Built-in safety circuitry protects the amplifier from overheating, electrical issues, or damage caused by improper connections.
-
Selectable Bass Optimization EQ (0dB-12dB) – Lets you boost the bass level to match your music style and listening preference, from natural bass to a deeper, more powerful sound.
-
Marine / Powersport / Off-road Compatible – Designed for use in boats, UTVs, ATVs, and other outdoor vehicles where durability and weather resistance are essential.
Specifications
| 4 x 125 Watts @ 4 ohms |
| 4 x 185 Watts @ 2 ohms |
| 2 x 325 Watts @ 4ohms (Bridged) |
| Ch 1/2 High Pass / Low Pass Filter Variable: 50 Hz – 4 Khz |
| Ch 3/4 High Pass / low Pass Filter Variable: 50 Hz – 4 KHz |
| Working Voltage: 9- 16 Volts |
| Frequency Response: 20Hz – 20KHz |
| Signal to Noise Ratio @ Rated Power 91dB |
| Low Level Input Range : 300MV – 6V |
| DIMENSIONS |
| L- 9.92″/ 252 mm |
| W- 4.88″/ 124 mm |
| H- 1.90″/ 48.5 mm |
Description
In the Box
The EMA-600.4 box includes the following components:
- 1 EMA-600.4 amplifier
- 1 user manual with warranty statement
- 1 Euphoria brand sticker
- 1 marine-grade power connection wire harness
- Marine-grade Installation tools
Product Manual
Product Manual PDF
