Description
Overview
Control the soundtrack of your escape.
The EMR-7BT keeps your music flowing effortlessly, putting seamless command at your fingertips while delivering A Higher Standard of Sound.
Features
- 3.0″ Full Color TFT Display – Bright, easy-to-read screen that shows music information, settings, and system controls in full color.
- Customizable RGB Illumination With Dimmer – Choose from multiple lighting colors to match your boat’s style, and adjust the brightness for day or night use.
- Backlit Display And Buttons – Illuminated screen and buttons make the receiver easy to see and operate even in low-light conditions.
- AM / FM Tuner – Listen to your favorite local AM and FM radio stations while on the water.
- Weather Band Tuner – Access NOAA weather channels to stay informed about changing weather conditions while boating.
- Built-In 4CH Amplifier – Internal amplifier powers up to four speakers directly from the receiver for clear, powerful sound.
- Built-In Bluetooth® For Music Streaming With ID3 Tag – Wirelessly stream music from your smartphone or tablet, while the display shows song information like artist and track name.
- USB Input – Connect a USB drive to play stored music files directly through the receiver.
- IP66-Rated Water-Resistant Control Face – Designed to resist water, dust, and harsh marine conditions for reliable performance on the water.
- User Customizable 10-Band EQ – Adjust different sound frequencies to fine-tune your music and create the sound profile you prefer.
- AUX Audio – RCA Input – Connect external audio devices using standard RCA cables.
- Camera Video Input – Supports connection of a camera for improved visibility and safety while maneuvering your boat.
- Protective Face Panel Cover Included – A removable cover helps protect the receiver from water, sun exposure, and debris when not in use.
Specifications
| Selectable high-pass crossover for Zone 1 and Zone 2 speakers |
| 2-zone independent volume control |
| Subwoofer Volume control with selectable low pass crossover |
| 5 preset EQ settings |
| 6-channel 5-volt – preamp outputs (front, rear, subwoofer) |
| Fuse value: 15 amps |
| Operating Voltage: 12VDC – 16VDC |
| Standby current draw: 5mA |
| Operating Temperature: -4F to +158F (-20C to +70C) |
| 25 watts RMS per channel |
| 50 watts peak per channel |
| RCA outputs @ 5 Volts |
| Tuner |
| FM – 18 Presets: 87.5 MHz to 108 MHz |
| AM – 12 Presets: 522kHz to 1720kHz |
| Bluetooth : Connection Range up to 30ft / 10 Meters |
| USB: Supported Audio Formats: MP3, WMA, AAC, FLAC, MP4, MP5 |
| Cutout Dimensions: 3.0″(W) x 4.0″ (D) 76.2mm(W) x 101.6mm(D) |
In the Box
- 1 EMR-7BT Media Source Unit
- 1 Power Connections Wire Harness
- 1 Mounting Gasket
- 1 Mounting Template
- 4 Mounting Screws
- 1 UV Protection Cover
- 1 User Manual with Warranty Statement
Product Manual
Product Manual PDF
