Description
Hifonics HCC35CX
The Hifonics HCC35CX is a 3.5″ 2-way coaxial car speaker from the Colossus Classic Series, designed for compact factory locations like dashboards and small speaker slots. It features woven fiber cones, 1″ aluminum dome tweeters, and a built-in passive crossover, delivering clear highs and balanced midrange in a compact, easy-to-install design.
Specifications
| Specification | Details |
|---|---|
| Type | Speaker |
| Brand | Hifonics |
| Series | COLOSSUS CLASSIC |
| Category | Mobile |
| Condition | New |
| Color | Black / Blue |
| Warranty | 1 Year |
| Compatible Vehicles | Universal |
| RMS Power Handling | 25 watts |
| Peak Power Handling | 50 watts |
| Impedance | 4 ohms |
| Frequency Response | 80Hz – 20kHz |
| Sensitivity | 88 dB |
| Crossover Slope | 6kHz 12dB |
| Mounting Diameter / Cut Out | 3.41 inches |
| Outside Diameter | 3.41 inches (No Grill) |
| Mounting Depth / Chassis Depth | 1.5 inches |
| Speaker Size | 3.5 inches |
Features & Benefits
| Tweeters | 1-inch aluminum dome tweeters deliver high output, extend frequency response, and keep music reproduction feeling natural. |
|---|---|
| Cone Material | Lightweight blue woven fiber cones enables faster midrange response. |
| Surround / Cone Coupling | Butyl rubber surrounds provide durability and deeper mid-bass impact. |
| Voice Coil / Former Assembly | Pure copper voice coil creates strong magnetic field with a very thin extrusion. The Kapton former assembly is lightweight and efficiently dissipates heat. |
| Spider | Epoxy infused natural fiber allows flexibility while the epoxy which gives strength during the manufacturing process. |
| Cooling System | Overcoil coolling system allows air to be exchanged over the voice coil through the spider. |
| Crossover | Passive Butterworth crossover gives smooth transition of frequencies from midrange/midbass to the tweeter element. |
| Frame | Anti-resonant stamped steel basket strengthens the whole speaker assembly with minimal harmonics or distortion from flex and ringing. |
| Motor | Ferrite magnet creates a strong magnetic field while remaining small enough to fit nearly every application. |
| Connectors | Spade connectors or solder direct for the best connection. |
| Grills | No: These speakers are typically installed behind an OEM panel. |
