Description
Features
| Class D circuitry |
| Audiophile grade components |
| Variable high pass -band pass- low pass crossover |
| Ultra high efficiency mosfet design |
| Heat management system |
| Selectable input gain range |
| 4 Layer PCB |
| 2Ω stereo / 4Ω Bridged capability |
Specifications
| 4 x 75 Watts @ 4Ω |
| 4 x 150 Watts @ 2Ω |
| 2 x 300 Watts @ 4Ω (bridged) |
| Ch 1-2 High Pass Crossover: 20Hz- 5kHz |
| Ch 1-2 Low Pass Crossover: 50Hz- 5kHz |
| Ch 3-4 High pass Crossover: 20Hz- 5kHz |
| Ch 3-4 Low pass Crossover: 50Hz- 5kHz |
| Crossover Slope @ 12 dB |
| Bass Boost @ 45Hz : 0-12dB |
| Input Sensitivity: 250Mv – 6V |
| Signal to Noise ratio : >92dB |
| Frequency Response:10Hz-22KHz |
| DIMENSIONS: |
| L: 7″ / 178mm |
| W: 5.50″ / 140mm |
| H: 2″ / 51mm |
