Description
Features
| 4 Channel Class A/B Circuitry |
| 2 Ω Stereo load Capability |
| low level RCA inputs |
| Selectable Crossover: HPF/LPF/BP |
| Bridgeable outputs @ 4Ω load |
| 4 gauge Power cable input connectors |
| Compatible with any 4/2Ω Loudspeaker |
| High Efficiency Mosfet Design |
| Heat Management System |
Specifications
| 4x 100 Watts @ 4 Ω Stereo |
| 4 x 200 Watts @ 2 Ω Stereo |
| 2 x 400Watts @ 4 Ω Bridged |
| Compatibility 2 Ω Stereo |
| THD at Rated Power <0.5% |
| Bandwidth (-3 dB) – 18Hz- 22KHz |
| Damping Factor (1k Hz @ 4Ω) – 100 |
| Signal to Noise Ratio >90dB |
| Input Sensitivity: 200Mv – 6V |
| Minimum Load Impedance – 2Ω Stereo |
| Input : Pre in RCA |
| Crossover filter slope in stereo – 12dB |
| Channel 1-2 HP filter range – 20Hz – 3.5KHz |
| Channel 3-4 HP filter range – 20Hz – 250Hz |
| Channel 3-4 LP/BP filter range – 50Hz – 250Hz |
| Selectable Bass Boost @45Hz – 0-12dB |
| 275mm |
| W – 237.38mm |
| H – 52mm |
